mb8611 firmware

My Motorola mb8611 kept rebooting frequently as mentioned in other posts I found in this forum.

I guess it may be related to firmware update, because a few times I logged into 192.168.100.1, I noticed a different firmware version.

The device seemed coming with firmware version 8611-19.2.18. And sometime after a rebooting, it became 8611-21.3.7. Then it would reboot again soon and rolling back to 8611-19.2.18.

How could I get stable connection without changing to a new devices?

Also post the signal status below.

 Downstream Bonded Channels

   Channel Lock Status Modulation Channel ID Freq. (MHz) Pwr (dBmV) SNR (dB) Corrected Uncorrected
   1 Locked QAM256 20 507.0 -1.6 40.8 0 0
   2 Locked QAM256 4 405.0 -1.5 41.2 0 0
   3 Locked QAM256 5 411.0 -1.3 41.5 0 0
   4 Locked QAM256 6 417.0 -1.3 41.5 0 0
   5 Locked QAM256 7 423.0 -1.2 41.5 0 0
   6 Locked QAM256 8 429.0 -1.3 41.7 0 0
   7 Locked QAM256 9 435.0 -1.3 41.7 0 0
   8 Locked QAM256 10 441.0 -1.4 41.8 0 0
   9 Locked QAM256 11 447.0 -1.1 41.9 0 0
   10 Locked QAM256 12 453.0 -1.0 41.9 0 0
   11 Locked QAM256 13 459.0 -1.3 41.7 0 0
   12 Locked QAM256 14 465.0 -1.5 41.8 0 0
   13 Locked QAM256 15 471.0 -1.4 41.6 0 0
   14 Locked QAM256 16 477.0 -1.2 42.0 0 0
   15 Locked QAM256 17 483.0 -1.2 41.9 0 0
   16 Locked QAM256 18 489.0 -1.2 41.8 0 0
   17 Locked QAM256 19 495.0 -1.6 41.5 0 0
   18 Locked QAM256 21 513.0 -1.4 41.3 0 0
   19 Locked QAM256 22 519.0 -1.3 41.8 0 0
   20 Locked QAM256 23 525.0 -1.4 41.6 0 0
   21 Locked QAM256 24 531.0 -1.5 41.6 0 0
   22 Locked QAM256 25 543.0 -1.6 41.4 0 0
   23 Locked QAM256 26 549.0 -1.5 41.6 0 0
   24 Locked QAM256 27 555.0 -1.2 41.7 0 0
   25 Locked QAM256 28 561.0 -1.1 41.7 0 0
   26 Locked QAM256 29 567.0 -1.1 41.7 0 0
   27 Locked QAM256 30 573.0 -1.3 41.8 0 0
   28 Locked QAM256 31 579.0 -1.3 41.8 0 0
   29 Locked QAM256 32 585.0 -1.2 41.7 0 0
   30 Locked QAM256 33 591.0 -1.0 41.8 0 0
   31 Locked QAM256 34 597.0 -1.0 41.9 0 0
   32 Locked OFDM PLC 48 688.0 -0.9 41.7 43877307 0


   Upstream Bonded Channels

   Channel Lock Status Channel Type Channel ID Symb. Rate (Ksym/sec) Freq. (MHz) Pwr (dBmV)
   1 Locked SC-QAM 1 2560 10.4 45.0
   2 Locked SC-QAM 2 5120 16.4 42.5
   3 Locked SC-QAM 3 5120 22.8 41.8
   4 Locked SC-QAM 4 5120 29.2 41.3
   5 Locked SC-QAM 5 5120 35.6 41.8
   6 Locked SC-QAM 11 2560 40.4 44.5

Event log showed the following critical messages:
SYNC Timing Synchronization failure - Failed to acquire QAM/QPSK symbol timing;
No Ranging Response received - T3 time-out;

Visitor

 •

5 Messages

2 years ago

Piling on here, I have the same issue with the same modem.  This modem has been supported by comcast for a long time and up until recently worked great.  I have posted in the forums here and direct messaged the xfinity support team via the provided method.  I have received no response nor acknowledgement of my issue.  Apparently xfinity feels they bear no responsibility despite the fact that they are the ones creating the issue.  Really disgusted by the poor level of customer support here and lack of ownership of this technical issue.

Official Employee

 •

3.1K Messages

Hey there, thanks for reaching out through Xfinity Forums regarding your connection issues. We would be happy to help you with troubleshooting your connection and your modem. I see you sent in a Private Message, and we would be happy to help you there.

I am an Official Xfinity Employee.
Official Employees are from multiple teams within Xfinity: CARE, Product, Leadership.
We ask that you post publicly so people with similar questions may benefit from the conversation.
Was your question answered? Please, mark a reply as the Accepted Answer.tick

Contributor

 •

28 Messages

This issue has never been trouble shooted based on all the posts.  Please show me one customer who had their modem issue resolved in these posts...  There currently is no resolution.

Visitor

 •

1 Message

2 years ago

Here's another MB8611 user experiencing reboots nearly twice an hour for the last 6 hours. This is completely unacceptable.

I'm working from home. If it's this bad tomorrow I don't know how I'm going to get any work done

Visitor

 •

2 Messages

2 years ago

I capture BM8611 modem stats and sent it to Motorola support, they reply:
"Thank you for providing that information. Looking at this there seems to be something wrong with your coaxial cable coming into the device. Your corrected/uncorrected numbers in the downstream bonded channels box should be at 0. Those are all errors coming into the device through that line. I would have your service provider come out and check those lines. As soon as they do, and fix that problem, you will be able to use your service without interruptions."

This issue (freeze and reboot) starts early January, I use modem one month before with no one reboot. Just analyze what you change in firmware and roll it back. You may make update or setup old firmware version for our modems that work fine with your network communication equipment.

Just take old firmware from Motorola and send update to our modems, as you do with current unstable version.

P/S my modem reboots 20+ times today. You must do something.

(edited)

Official Employee

 •

455 Messages

Hello @user_vaus202 I am sorry to hear of the issues that you are having with your services. You have come to the right place. I would be happy to look over your account to see if there are any issues. Before we get started, could you please send our team a direct message with your full name and full address? Our team can most definitely take a further look at this issue. To send a "Peer to peer" ("Private") message: Click "Sign In" if necessary

• Click the "Peer to peer chat" icon

• Click the "New message" (pencil and paper) icon

• Type "Xfinity Support" in the "To:" line and select "Xfinity Support" from the drop-down list which appears. The "Xfinity Support" graphic replaces the "To:" line

• Type your message in the text area near the bottom of the window

• Press Enter to send it

I no longer work for Comcast.

I am an Official Xfinity Employee.
Official Employees are from multiple teams within Xfinity: CARE, Product, Leadership.
We ask that you post publicly so people with similar questions may benefit from the conversation.
Was your question answered? Please, mark a reply as the Accepted Answer.tick

Visitor

 •

1 Message

Is there any resolution to this issue? I am also facing precisely the same problem and the modem keeps rebooting. This is causing significant disruption. Can Xfinity team please look into it and provide a resolution?

Info: - My modem shows the software version 8611-21.3.7 and appears to be the same even after reboot.

Contributor

 •

18 Messages

The only solution that seems to be working is to buy a new modem.  I had the same problem everyone else was having and just ended up buying a Netgear CM2000 and haven't had an issue in over two days now.

Visitor

 •

1 Message

I also have been getting the same disconnect issues several times per day as reported in this thread. Very frustrating when trying to work from home and have been getting disconnected from the internet several times per day for over a month now. I have tried a factory reset of the modem, as well as connecting the modem directly to the coax cable coming into my house, taking my active return splitter out of the equation for troubleshooting purposes. In my modem event log I get several of the same critical errors at the times of reboot, similar to others reported in this thread. Would appreciate it if I can get connected with someone at Xfinity here. I see references to being able to send a DM, but I dont have that option in my toolbar.

(edited)

Official Employee

 •

915 Messages

Hey there, @user_275e15. Typically, it is a signal issue that would cause the intermittent connection you're experiencing through your modem, not normally a firmware update. The power levels tied to the original thread posting are what is leading me to that assumption. But you know what they say about folks who make assumptions lol. If you could please send me a DM with your first and last name along with your full-service address, we can get started diving into your connection issues from this end.



To send a "Direct Message" to Xfinity Support:

Click "Sign In" if necessary

Click the "Direct Messaging" icon or https://comca.st/3EqVMu7

Click the "New message" (pencil and paper) icon

The "To:" line prompts you to "Type the name of a person". Instead, type "Xfinity Support" there

 - As you are typing a drop-down list appears. Select "Xfinity Support" from that list

 - An "Xfinity Support" graphic replaces the "To:" line

Type your message in the text area near the bottom of the window

Press Enter to send it

See https://comca.st/3KQF8q9 for an example.

I am an Official Xfinity Employee.
Official Employees are from multiple teams within Xfinity: CARE, Product, Leadership.
We ask that you post publicly so people with similar questions may benefit from the conversation.
Was your question answered? Please, mark a reply as the Accepted Answer.tick

Expert

 •

110.4K Messages

2 years ago

@user_4bffe4

Your post with that first pic of the Device Information was marked as being "Private" by the forum software because it contains CM MAC and the CMTS MAC addresses. They are considered to be personal information. The posting of personally identifiable information is a violation of their forum guidelines. Please delete that pic only. Thank you.

Visitor

 •

3 Messages

2 years ago

Any updates on a fix? I have been having these issues since December! And just found this issue is related to the 21.3.7 firmware. Has comcast mentioned a fix yet?

Visitor

 •

1 Message

2 years ago

This is frustrating, this is what Comcast advises

“I can check the Xfinity internet connectivity for you. If it’s a modem issue you need to contact modem manufacturer to check modem.”

Ashish

Official Employee

 •

746 Messages

Hi,  thank you for reaching out to Xfinity. I understand you are having connection concerns. It seems the latest update may have caused connection issues with your purchased modem. Has a specialist troubleshot your modem? Has a tech visited? If the issue persists I see the other option is to purchase a different modem that is compatible with the services. Based on feedback, customers that have been  having this issue have purchased a different modem and the connection issue was resolved.

I no longer work for Comcast.

I am an Official Xfinity Employee.
Official Employees are from multiple teams within Xfinity: CARE, Product, Leadership.
We ask that you post publicly so people with similar questions may benefit from the conversation.
Was your question answered? Please, mark a reply as the Accepted Answer.tick

Visitor

 •

3 Messages

2 years ago

As with everyone else, I have no problems with firmware version  8611-19.2.18 , It is only once comcast pushes through 8611-21.3.7 do I constantly lose internet

Contributor

 •

72 Messages

2 years ago

I know this post has gotten old, but I thought I'd mention something I noticed about two weeks ago. Quick recap: I have a new Xfinity install as of December 2022 and have a Motorola MB8611 modem + my own router. When I got the modem, it had firmware version 8611-19.2.18. A few weeks later, it was upgraded to 8611-21.3.7. However, unlike most people posting here, I had no problems with the Internet dropping out on either version.

Two weeks ago, I noticed that the blue downstream arrow on the modem was blinking, which means the modem is "Negotiating bonded channel(s)," according to the MB8611 Quick Start Guide. This has happened a few times, and rebooting the modem fixes it for quite a while. I logged into the modem to reboot it and found that the firmware version had been downgraded to 8611-19.2.18 on February 17th. I wanted to give it a few days to see if it "stuck" or got upgraded back to 8611-21.3.7. It's been two weeks, and the firmware version has stayed at 8611-19.2.18. I am guessing that Xfinity's temporary fix is to downgrade all MB8611s to the older firmware until Motorola creates a new version (hopefully without the disconnection issues).

Side note: the MB8611 Quick Start Guide has a footnote for the blinking downstream light saying: "If a blue Upstream or Downstream light blinks continuously, this indicates partial service (at least one designated channel has not completed bonding). You should still get high Internet speeds, but your service provider may want to know so they can adjust their network."

Visitor

 •

7 Messages

2 years ago

I also posted this on this thread: https://forums.xfinity.com/conversations/your-home-network/motorola-mb8611-modem-keeps-restarting-firmware-issue/63bb6c5b507b4d3af9e1b39e?page=3

I guess I am a bit late to the sad party, but I am having the same issues. I've been having these issues consistently for the last 6 months, maybe longer tbh, but I don't remember when they first started.

Here is what I've done so far, but again, the problem still persists.

  1. Had Comcast run a new line from the pole into my house (to be fair the line was probably 10-15 years old)
  2. Had Comcast replacee a peice of hardware on the line, where my cable line plugged into
  3. RMAed my modem with Motorola and replaced it 2 weeks ago (took a little back and forth with them but not a long time)

Today, I spent 1.5 hours with the most technical Comcast Tech I've worked with so far and basically he found nothing. He checked pretty much everything, and showed me everything he was checking. We compared all that he was checking with my "Connection" info (from the Motorola Admin screen) and everything seemed great.

I never thought to check the version number of the modem's software, but I am currently on 19.2.18 (I hard reset my modem today tho)

I hard reset my modem today, so unsure if this was the a different version before this and I don't know what version I was on with my older peice of hardware. Either way, this is really disappointing becuase Comcast should not recommend this hardware (obviously this is an issue) and Motorola should not sell it (or both Companies should ideally fix it, but that doesn't seem like it's going to happen).

My next steps are to try another non-Motorola modem - either by renting or buying a new one and trying to return it before the 30 day mark (or sell the Motorola one online).

If anyone has any questions, happy to answer.

Visitor

 •

3 Messages

@user_aee417​ Like the previous guy said, The issue seems to have stopped a few weeks ago. I am stable again operating on the previous firmware version. Id give it a few days, and see if your issue happens again, and if it does, check which firmware your on.

Coincidently the day I posted I also called the xfinity support. They tried to do all the basic troubleshooting steps, like they made you do. But I insisted that was not the problem and directed them to this page. Support ended up admitting about knowing about the problem and that it was unlikely they would revert to the previous version. They said all I could do was wait for a new firmware version to come out or rent their modem. At which point I requested a refund on my service. Two days later, my modem reverted to the previous version and I have not had an issue since...

(edited)

Visitor

 •

7 Messages

@user_4c5469 It's still an issue for me :(

For the last 4 days (maybe even longer) had 0 interuptions while on 19.2.18 version. This morning, my modem restarted 3 times and now has been up for the last 9 hours. Same version #.

#sad

Visitor

 •

7 Messages

2 more times today....so far. Sitll on 19.2.18 version

Visitor

 •

7 Messages

Also from Motorola's support:

"Firmware/Software has to be updated by the ISP as all cable modems and cable modem routers need to have firmware that is compatible with their network. They are the ones that must provide an update for the issue, we are assisting them but again they are in control of updates so we cannot provide a completion estimate."

Visitor

 •

5 Messages

2 years ago

So if I am having this issue, how can I get the 21.3.7 firmware update?  I’m about to switch to T-Mobile internet since I need a reliable connection but I am willing to try one more thing. I have been dealing with this for over a year and have had 4 technicians come out and only noticed this today when the technician told me to update my firmware
